Stormchaser Apex Eagle SUS is an adventure-ready gravel bike with suspension for seeking out the roughest tracks. The 6066-T6 alloy frame features our Class 5™ VRS to cut road chatter, and a RockShox Rudy XPLR suspension fork doubles down on comfort with 40mm of travel. A dropper post makes it easier to shift your weight to navigate obstacles and descend with complete confidence.
Frameset
- Frame
- Stormchaser
- Fork
- RockShox Rudy XPLR, 40 mm
- Color
- Berry
- Rear Shock
- N/A
Drivetrain
- Front Derailleur
- N/A
- Rear Derailleur
- SRAM Apex Eagle
- Cassette
- SRAM PG-1210, 11–50t, 12-speed
- Chain
- SRAM NX Eagle
- Crankset
- Race Face Ride, 38t
- Shifter
- SRAM Apex
- Brake and Rotors
- SRAM Apex HRD hydraulic brakes, SRAM CenterLine rotors (Center Lock, 160 mm)
Components
- Headset
- FSA No.42 ACB
- Stem
- Salsa Guide
- Handlebar
- Salsa Cowchipper
- Grips
- Velo anti-slip, shock-proof silicone tape
- Seatpost
- TranzX YP38 Dropper Post, 27.2, 90 mm travel
- Saddle
- WTB Volt Medium Steel
Wheels
- Front Wheel
- Shimano RS470, 12 x 100 mm hub, WTB EZR TCS 2.0 i25 29" rim, 28h (taped for tubeless, WTB tubeless valve included). Tubes installed
- Rear Wheel
- Shimano RS470, 12 x 142 mm hub, WTB EZR TCS 2.0 i25 29" rim, 28h (taped for tubeless, WTB tubeless valve included). Tubes installed
- Tires
- Teravail Rutland 700 x 47 mm, tubeless ready, Durable casing
*Specification and pricing subject to change without notice.
- Design Wheel/Tire Sizes
- 700c x 42 mm
- Alternate Wheel/Tire Sizes
- 700c x 32–50 mm; 650b x 47–50 mm
- Suspension Fork Length (Travel)
- 435mm (40mm)
- Rigid Fork Length
- 420 mm
- Fork Offset
- 51 mm
- Headset, Upper
- IS41
- Headset, Lower
- IS52
- Seatpost
- 27.2 mm
- Seatpost Collar
- 32.0 mm
- Dropper Compatible (Routing)
- Yes (internal)
- Front Derailleur Clamp
- N/A
- Front Derailleur Type
- N/A
- Bottom Bracket
- 73 mm BSA, threaded
- Crankset (Max Ring - Single Speed)
- 1x crankset, 40t max, Race Face/Easton 51 mm chainline, single speed only
- Crankset (Max Ring - Geared)
- 1x crankset only, 38t max, 49 mm MTN chainline, 168 Q-factor min.
- Front Brake (Rotor)
- Flat mount frame standard, 35 mm thickness, 42 mm bolt length (160 mm rotor only)
- Rear Brake (Rotor)
- Flat mount frame standard, 20 mm thickness, 27 mm bolt length (140–160 mm rotor)
- Rear Spacing
- 12 x 142 mm TA
- Rear Axle Size
- M12 x 167L, TP = 1.5, TL = 20 mm (NOTE, DOES NOT FIT SALSA DEABOLT W/ LEVER. DEADBOLT UL TOOLED AXLE ONLY)
- Derailleur Hanger
- Hanger 465, QBP# FS2322 (Requires geared Alternator Flat Mount Plate, QBP# FS0719, and Hanger Axle/Stud Kit, QBP# FS1181)
- Rear Rack Mounts
- Yes, universal rack rear compatible. Salsa Post-Lock seat collar required. Salsa Wanderlust Rack recommended.
- Fender Mounts
- Yes, required fender hardware included.
- Max Tire Size with Fenders
- 700c x 47 mm
- Water Bottle Mounts
- Frames up to 56 cm: 2 in main triangle. Frames 57.5 cm and larger: 3 in main triangle.
- Downtube Accessory Mounts
- One
- Top Tube Mounts
- Yes, compatible with Salsa EXP Series Top Tube bag.
- Stem Clamp
- 28.6 mm
- Crown Race
- Integrated SHIS 40, 36° Angle
- Front Spacing
- 12 x 100 mm TA
- Front Axle
- M12 x 120L, TP = 1.5, TL = 12 mm
- Three-Pack Mounts
- One mount per fork leg.
- Rack Mounts
- 165 mm Low-rider compatible. Salsa Down Under rack recommended.
Size |
49cm |
52.5cm |
54.5cm |
56cm |
57.5cm |
59cm |
61cm |
A. Effective Top Tube |
508 |
529 |
548 |
563 |
578 |
593 |
608 |
B. Stand Over |
697 |
736 |
766 |
794 |
807 |
829 |
851 |
C. Reach |
359 |
363 |
365 |
374 |
383 |
392 |
402 |
Crank Arm Length |
165 |
165 |
165 |
170 |
170 |
170 |
170 |
D. Stack |
535 |
549 |
568 |
587 |
606 |
625 |
644 |
E. Total Seat Tube Length |
390 |
440 |
475 |
510 |
520 |
545 |
570 |
F. Headtube Length |
90 |
105 |
125 |
145 |
165 |
185 |
205 |
G. Headtube Angle |
70 |
70 |
70 |
70 |
70 |
70 |
70 |
H. Seat Tube Angle |
75.25 |
74 |
73 |
73 |
73 |
73 |
73.1 |
Handlebar Width |
40cm |
42cm |
44cm |
46cm |
48cm |
50cm |
52 |
I. BB Drop |
64 |
64 |
64 |
64 |
64 |
64 |
64 |
J. BB Height |
290 |
290 |
290 |
290 |
290 |
290 |
290 |
K. Chainstay Length |
435–450 |
435–450 |
435–450 |
435–450 |
435–450 |
435–450 |
435–450 |
L. Fork Length Axle to Crown |
433 |
433 |
433 |
433 |
433 |
433 |
433 |
M. Fork Offset |
51 |
51 |
51 |
51 |
51 |
51 |
51 |
N. Wheelbase |
1023.1–1043.3 |
1032.8–1052.9 |
1041.5–1061.6 |
1057.6–1077.7 |
1073.7–1093.6 |
1089.8–1109.6 |
1107.1–1126.9 |
Recommended Rider Height |
142cm–157cm |
155cm–165cm |
162cm–173cm |
170cm–180cm |
178cm–188cm |
185cm–193cm |
190cm–UP |
Stem Length |
60 |
70 |
80 |
90 |
90 |
100 |
110 |
Measurements based on:
- a fork measuring 435x51mm which is equivalent to an average 40mm suspension fork at 5% sag
- a 700x47mm tire measuring 721 mm in diameter
- standover (B) measured vertically to top of toptube from a position 50mm forward of BB center.
